Computer System

Processor: Intel Atom Cedarview-D2550 Dual Core 1.86G L2 1M 10W /Intel Celeron 1037U Dual Core Clock ClocSpeed 1.8G TDP 17W /Intel Core I3-3227U Dual Core 1.9G 17W
Chipset: CPU Integrated Graphic+Nm10 /Intel Nm70 TDP 4.1W /I3-3227U+HM76

Display Chip:Intel GMA3650 D×9 /Intel GMA HD Graphic D×11 /Intel HD 4000
Memory: 2GB DDR3 1333MHz1*SO-DIMM slot up to 4GB
HDD: MSATA32/64/128GB SSD or 2.5" 500GB HDD
Ethernet: Realtek 8103EL 10/100M

Power in: AC 100V～230V
Support diskless boot

I/O port
Serial Port:×3
Parallel port:×1
VGA: ×1
USB: ×4
RJ45: ×1
AC in: ×1

Audio Jack:MIC in & SPK out

Package Information

Carton Size(mm):

390(L)×160(W)×350(H)

G.W:3.9kgs
