Touch System

Touch Screen: 5-wire Resistive Touch Screen
Touch Screen Interface: USB or Serial Port
Touch Life: 35,000,000 times

Display System
View Size: 15 Inch
Display Type: TFT LCD
Resolution: 800×600 1024×768
Display Colors: 16.7M
Contrast radio: 450:1
Video In: VGA R/G/B
Response time: 12ms

Computer System

Processor: Intel Atom Cedarview-D2550 Dual Core 1.86G L2 1M 10W /Intel Celeron 1037U Dual Core Clock ClocSpeed 1.8G TDP 17W /Intel Core I3-3227U Dual Core 1.9G 17W
Chipset: CPU Integrated Graphic+Nm10 /Intel Nm70 TDP 4.1W /I3-3227U+HM76

Display Chip:Intel GMA3650 D×9 /Intel GMA HD Graphic D×11 /Intel HD 4000
Memory: 2GB DDR3 1333MHz1*SO-DIMM slot up to 4GB
HDD: MSATA32/64/128GB SSD or 2.5" 500GB HDD
Ethernet: Realtek 8103EL 10/100M
Support diskless boot

Optional Accessory
Card Reader: 1&2&3 Tracks Magnetic
Stripe Card Reader / Inductive ID Card Reader
Customer Display: LED / VFD / LCD
2nd Display: 15 Inch LCD Monitor
Wireless Module: 802.11a/b/g/n
Fingerprint Scanners: optical

I/O port
Serial Port:×3
Parallel port:×1
VGA: ×1
USB: ×4
RJ45: ×1
AC in: ×1

Audio Jack:MIC in & SPK out

Package Information

Carton Size(mm):

500(L)×300(W)×470(H)

G.W:8kgs
